The new Audison DRC MP (Digital Remote Control Multimedia Play) is compatible with all the Audison electronics featuring AC Link bus. Its slim profile along with the holder supplied with it eases the installation in the best position inside the car. Thanks to the new Joystick, “Rubber Touch” finished for best control of the movements along the four direction axes, the “DRC Settings” menu can be adjusted and navigation is also possible through the “Navi Command” function if the system features an Audison bit Play HD with video output connected to a monitor.

USE

The C2O interface converts the signals coming from the coaxial digital input and from the analog AUX-IN into a TOSLINK optical digital output signal (up to 24 bit/192kHz).

The conversion allows the integration of the new Hi-Res portable devices equipped with coaxial digital output (75Ω) and smartphones with analog output on 3.5 mm mini Jack (also 4 poles) with Audison processors featuring an optical digital input compatible with the resolution of the signal sent to the C20.

Thanks to its extreme compactness, the C20 can be installed in a hidden position on the dashboard, drastically reducing the length of the cabling between the portable player and the receiving device nullifying in this way any issues with interfacing.

FEATURES

The coaxial digital input is provided with an isolation transformer that improves the balance between the transmitter and the receiver circuit, reducing noise due to EMI electromagnetic interference, which is particularly insidious inside the passenger compartment.

The AUX-IN input is equipped with a pre-amplifier with adjustable gain of 0.1V ÷ 2V for an optimal coupling with each device before the Analog-Digital conversion is performed by a high quality converter at a resolution of 24 bit/48 kHz.

For maximum ease of use in cars, the C2O independently selects the input with priority assigned to the AUX-IN. With the default setting, after 6 seconds of no analog signal, the C2O moves to the coaxial digital input. An internal switch allows for the time before the switch to be set to 9 or 12 seconds.

Stereo passive mixer (unpowered) featuring 4 input channels and 2 output channels, designed for active OEM multi-way systems where each speaker is powered by one specific amplified channel. SPM4 mixes audio through 4 audio transformers specifically developed to achieve very low distortion and highly linear acoustic response. SPM4 provides the ability to mix the midrange/woofer and tweeter channels coming from the amplifier and supply one single mid-high channel. The Ch1(L/R) channels feature two inputs, one features an inverting input compared to Ch2 (L/R) channels; the mixing process often gives better results when one of the two channels undergoes a 180° dephasing. SPM4 is especially recommended to extend the number of inputs of the Audison digital processors or amplifiers with built-in DSP because they feature a De-equalizer (De-Eq). In that case, any possible non-linear acoustic emissions due to the mixing of the pre-existing filtered channels are duly compensated.

It prevents the processor from shutting down when turning on vehicles featuring the start & stop system

When starting the engine, the vehicle battery voltage might decrease below 8 Volts value. If an Audison bit processor is installed in your system, especially with vehicles featuring the start & stop system, low supply voltage values might make the processor shut down. In order to avoid waiting for the processor to complete its turn-on cycle again, you can install the ES3 by connecting it in series to the processor power supply cables.

Male-Female Toslink adapter with rotating head. 90° angle shape to save space.

PACKAGE: Polybag Qty. 1

Optical adapter to extend optical cables featuring TOSLINK connectors.

PACKAGE: Polybag – Qty. 1

Optical digital audio signal cable, designed for car audio applications, allowing the transfer of the optical signal without signal loss. An especially thicker sheath protects the optical fibre to prevent the cable from damages if it is pressed against sharp edges. The sturdy connector connector protects the optical fibre along its full length, ensuring a stable transmission of the signal also in the event of strong vibrations.  Ending with Toslink connectors for S/PDIF digital audio signals.

Cable length 4,5 m/177,16”

PACKAGE: Polybag Qty. 1

Optical digital audio signal cable, designed for car audio applications, allowing the transfer of the optical signal without signal loss. An especially thicker sheath protects the optical fibre to prevent the cable from damages if it is pressed against sharp edges. The sturdy connector protects the optical fibre along its full length, ensuring a stable transmission of the signal also in the event of strong vibrations.  Ending with Toslink connectors for S/PDIF digital audio signals.

Cable length 1,5 m / 59,05”

PACKAGE: Polybag Qty. 1

It is a kit composed of a cable and an adapter allowing a 2 m / 78.74 in. additional extension of the cable supplied with the DRC. This extension is required for installations on especially long vehicles such as SUV’s. Total length of the supplied cable with the extension is equal to 6,5 m / 225.90 in.

PACKAGE: Polybag – Qty. 1
